140XEN-620300-001 Hydraulic Cylinder
40mm Bore ?? 20mm Rod ?? 125mm Stroke
Ever-power’s 140XEN-620300-001 hydraulic actuator brings together advanced seal technology and CNC-machined steel construction. The 40mm bore and 20mm rod diameters are optimized for the 125mm stroke requirements of contemporary forklift designs.
140XEN-620300-001
40 mm
20 mm
125 mm
400 mm
Ever-power has established itself as a premier industrial hydraulic cylinders through consistent quality and responsive support.
Product Overview
The 140XEN-620300-001 extends beyond nominal ratings. This 40mm bore maintains seal integrity at 1.5?? rated pressure with burst margins exceeding 2.5??. The 20mm rod deflection under maximum side load stays within 0.05% of unsupported length. The generous 20mm rod provides exceptional column strength resisting buckling under load.
Quality documentation accompanying each 140XEN-620300-001 includes material mill certificates, pressure test reports with pressure-time charts, dimensional inspection sheets, and seal material compliance certificates. Full traceability from raw material to finished goods is maintained via serialized traveler tags.
Key Features
Balanced Force Geometry
The 40mm ?? 20mm bore-to-rod ratio is optimized to produce predictable push and pull force characteristics. This eliminates jerky steering response during rapid pressure transients when navigating tight warehouse aisles or maneuvering in congested loading dock areas.
Induction-Hardened Core
The 20mm rod core achieves HRC 28-32 through induction hardening prior to chrome deposition. This substrate hardness supports the chrome layer against denting from impact loads during dock operations, pothole traversal, and rough terrain encountered in outdoor yard applications.
Cleanroom Assembly
Pistons and seals are installed in a controlled environment maintaining particle counts below Class 1000 levels. This prevents airborne contamination from causing internal scoring of precision-honed surfaces and premature seal degradation during initial break-in period.
CMM Verification
Coordinate Measuring Machine inspection confirms all critical dimensions including bore diameter, rod concentricity, stroke length accuracy within ??0.5mm, and mounting hole positional tolerances before release from quality hold.
Ever-power custom hydraulic cylinders expertise reduces downtime for demanding industrial applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 140XEN-620300-001 |
| Bore | 40.0 mm |
| Rod | 20.0 mm |
| Stroke | 125.0 mm |
| Mount | 400.0 mm |
| Work Pressure | 25 MPa |
| Test Pressure | 37.5 MPa |
| Burst | 62.5+ MPa |
| Temp Range | -30??C to +100??C |
| Fluid | Mineral Oil |
| Barrel | 27SiMn Seamless |
| Rod Surface | Hard Chrome 20+??m |
| Mounts | Pin Eye / Clevis |
| Ports | G1/4 or M14x1.5 |
Working Principle
Through Pascal’s principle, pressurized oil from the gear pump enters the 140XEN-620300-001’s 40mm bore. At 16-21 MPa typical for forklifts, pressure acts on the piston face creating force proportional to the bore area. The 20mm rod emerges, pivoting the steering linkage through an arc from 125mm stroke and lever geometry. Reversing the wheel switches valve position, pressurizing the rod-side chamber. The differential area means extension force exceeds retraction force.
Applications
The 140XEN-620300-001 is purpose-built for forklift steering systems where precise angular control and rapid response are non-negotiable. Its 40mm bore generates torque to pivot steer wheels through full arc, even when stationary and loaded. Narrow-aisle warehouses benefit from consistent steering feel reducing operator fatigue during long shifts. The unit also suits AGVs where repeatability determines navigation accuracy along defined paths. Marine terminal operations and cold storage facilities particularly value the responsive steering and low-temperature seal performance.
Brand Compatibility
OEM-grade specifications ensure seamless integration with TCM hydraulic systems at standard flow and pressure parameters. Rod end threads and gland dimensions match original components on Heli and Hangcha steer axles, eliminating adapter fittings. Technical datasheets with full dimensional drawings are available for engineering verification and BOM approval before purchase commitment.
Learn about hydraulic optimization in our hydraulic cylinder manufacturer article.
Customization Options
For volume OEMs, Ever-power provides dedicated engineering to adapt this platform. Development includes 3D modeling, FEA analysis, prototype production, and validation testing.
Mounts
Custom brackets, valve manifolds, dual-eye configs.
Speed
Built-in cushions, meter-out orifices, flow controls.
Sensors
Magnetic piston for reed switch or Hall effect.
Coding
OEM paint colors, laser marking for 40mm bore cylinders.
Manufacturing & Quality
ISO 9001 facility with SPC monitoring. Twin-spindle CNC machines both end bores for 0.05mm concentricity. Chrome verified at 8 points by XRF (20??m min). Positive-pressure assembly. Final test to 37.5 MPa with joint inspection.
Receipt
Mill test reports
Machining
CNC, twin-spindle
Surface
XRF chrome check
Clean Asm
Positive air pressure
Hydrotest
37.5 MPa gradual
Final QC
Dimensional, visual
How to Select the Right Hydraulic Cylinder
The selection process balances hydraulic system capability with mechanical constraints. Verify these parameters against equipment specs ?? bore 40mm, rod 20mm, stroke 125mm, mounting 400mm ?? considering duty cycle, fluid type, temperature range, and contamination exposure in your application.
- Calculate Forces
Extension: 25N. Retraction: 18N at 20 MPa. Verify these exceed application loads including safety margins for peak conditions. - Check Envelope Dimensions
Mounting 400mm, retracted 275mm, extended 400mm ?? verify against equipment clearances. Rod end must mate with steering linkage without modification. - Evaluate Environment
Temperature range, fluid type, duty cycle, contamination exposure determine seal selection and surface treatment for this 40mm bore cylinder in your specific conditions.
Structural Components
The 40mm barrel serves as pressure vessel and bearing housing ?? honed Ra 0.4??m eliminates separate liner need. End caps provide porting, mounting, and seal retention; torqued with anaerobic sealant against vibration loosening. The floating piston carries the polyurethane U-cup and two bronze-filled PTFE guide bands distributing side loads. The 20mm chrome rod exits through the head-end gland where triple-seal arrangement maintains zero leakage. Vent holes prevent pressure trapping behind the rod seal.
Piston
Ductile iron with PTFE wear bands
Gland
Threaded cartridge: seal, bearing, retention
End Caps
Steel forgings, CNC-machined, ported
Seal System
Multi-lip PU/NBR, self-energizing
Ever-power Technical Deep Dive
Certifications
Ever-power operates under ISO 9001:2015 certified by T??V Rheinland. Pressure testing follows ISO 10771:2015. The 20mm rod chrome meets RoHS 2011/65/EU. Full lot tracking links mill heat numbers to finished cylinder serial numbers.
Frequently Asked Questions
How to measure for 140XEN-620300-001?
Measure: extended pin-to-pin, retracted length, 40mm bore, 20mm rod, pin diameter. Stroke = extended ? retracted. Match within ??2mm.
What causes external leaks?
Rod leaks: wiper/rod seal failure or heat damage. Port leaks: loose fittings. Barrel leaks: O-ring wear. Most fixed with seal kit. Persistent leaks need exchange.
Technical drawings available?
PDF and STEP formats at no charge. Includes all dimensions, ports, mounts, weight, torque specs. Contact technical support with your request.
Delivery time?
Standard 20mm rod, 125mm stroke: 10-15 business days. Express: 5-7 days at 20% premium. Volume orders: phased delivery. Regional stock may ship immediately.
